The QMC6309H is a three-axis magnetic sensor, which integrates magnetic sensors and signal condition ASIC into one silicon chip. This wafer level chip scale package (WLCSP) is targeted for applications such as e-compass, map rotation, gaming and personal navigation in mobile and wearable devices.
The QMC6309H is based on state-of-the-art, high resolution, magneto-resistive technology. Along with the custom-designed 16-bit ADC ASIC, it offers the advantages of low noise, high accuracy, low power consumption, offset cancellation and temperature compensations. QMC6309H enables 1° to 2° compass heading accuracy. The I²C serial bus allows for easy interface.
The QMC6309H is in a 0.8x0.8x0.5mm³ surface mount 4-pin WLCSP package.
▪ 3-Axis Magneto-Resistive Sensors in a 0.8x0.8x0.5 mm³ WLCSP, Guaranteed to Operate Over an Extended Temperature Range of -40 °C to +85 °C
▪ 16 Bit ADC With Low Noise AMR Sensors Achieves 2 milli-Gauss Field Resolution
▪ Wide Magnetic Field Range (±32 Gauss)
▪ Temperature Compensated Data Output
▪ Built-In Self-Test
▪ Built-In FIFO with 8 frames of data
▪ Wide Range Operation Voltage (1.62V to 3.6V) and low Power Consumption less 10uA at 1Hz ODR
▪ Support 1.2v IO communication when Operation Voltage is 1.8v
▪ Lead Free Package Construction
▪ Software and Algorithm Support Available
▪ Small Size for Highly Integrated Products. Signals Have Been Digitized and Calibrated
▪ Enables 1° To 2° Degree Compass Heading Accuracy, Allows for Pedestrian Navigation and LBS Applications
▪ Maximizes Sensor’s Full Dynamic Range and Resolution
▪ Automatically Maintains Sensor’s Sensitivity Under Wide Operating Temperature Range
▪ Enables Low-Cost Functionality Test After Assembly in Production
▪ Compatible with Battery Powered Applications
▪ RoHS Compliance
▪ Compassing Heading, Hard Iron, Soft Iron, and Auto Calibration Libraries Available
